直流風(fēng)扇 JHX9238高增壓
9238 尺寸/Size 92X92X38mm DC Axial Flow Fan
★Dimensions Drawing(外觀(guān)圖） ★Characteristic Curves(特性曲線(xiàn))
|
★Specifications（規格） |
|||||||||
|
Model
型號 |
Bearing System 培林 |
Rated Voltage 電壓（V) |
Operation Voltage 電壓范圍 |
Current
電流（A) |
Input Power 功率（W) |
Speed 轉速 （RPM) |
Air Flow 風(fēng)量 （CFM） |
Static Pressure 靜壓（mm-H2O) |
Noise Level 噪音（dB-A） |
|
JHX9238X12H |
Sleeve Ball |
12 |
10.8~13.2 |
2.50 |
30.00 |
6000 |
139.87 |
238.79 |
61.0 |
|
JHX9238X12M |
1.80 |
21.60 |
5500 |
124.56 |
196.23 |
56.0 |
|||
|
JHX9238X12L |
0.90 |
10.80 |
4500 |
102.73 |
145.04 |
45.0 |
|||
|
JHX9238X24H |
Sleeve Ball |
24 |
15～27 |
1.50 |
36.00 |
6000 |
139.87 |
238.79 |
61.0 |
|
JHX9238X24M |
1.00 |
24.00 |
5500 |
124.56 |
196.23 |
56.0 |
|||
|
JHX9238X24L |
0.60 |
14.40 |
4500 |
102.73 |
145.04 |
45.0 |
|||
|
JHX9238X48H |
Sleeve Ball |
48 |
35～55 |
0.80 |
39.40 |
6000 |
139.87 |
238.79 |
61.0 |
|
JHX9238X48M |
0.60 |
28.80 |
5500 |
124.56 |
196.23 |
56.0 |
|||
|
JHX9238X48L |
0.30 |
14.40 |
4500 |
102.73 |
145.04 |
45.0 |
|||
