直流風(fēng)扇 JHX2507
2507 尺寸/Size 25X25X07mm DC AxialFlowFan
★Dimensions Drawing(外觀(guān)圖) ★Characteristic Curves(特性曲線(xiàn))
★Specifications(規格 |
|||||||||
Model
型號 |
Bearing System 培林 |
Rated Voltage 電壓(V) |
Operation Voltage 電壓范圍 |
Current
電流(A) |
Iuput Power 功率(W) |
Speed 轉速 (RPM) |
AirFlow 風(fēng)量 (CFM) |
Static Pressure 靜壓(mm-H2O) |
Niose Level 噪音(dB-A) |
JHX2507S05H |
Sleeve |
5 |
4.5~5.5 |
0.18 |
0.90 |
12000 |
1.97 |
39.03 |
30.0 |
JHX2507S05M |
0.15 |
0.75 |
10000 |
1.57 |
26.48 |
24.0 |
|||
JHX2507S05L |
0.12 |
0.60 |
8000 |
1.15 |
16.38 |
21.0 |
|||
JHX2507S12H |
Sleeve |
12 |
10.8~13.2 |
0.07 |
0.84 |
12000 |
0.97 |
39.03 |
30.0 |
JHX2507S12M |
0.05 |
0.60 |
10000 |
1.57 |
26.48 |
24.0 |
|||
JHX2507S12L |
0.04 |
0.48 |
8000 |
1.15 |
16.38 |
21.0 |
